Sku: RA0715-AS923

Availability: Many In Stock
Sku: RA0715-AS923

NETVOX Wireless Smoke Detector - RA0715 is equipped with temperature and humidity sensor externally. It can monitor the ambient temperature and humidity and send the data via wireless method that adopts SX1276 wireless communication module. RA0715 is equipped with CO2 sensor that can detect the concentration of CO2 in the air.


Example Applications

  •  Smart home
  •  Smart farm
  •  Other


    Features of NETVOX Sensors

    • Wireless range of 10 km *
    • LoRaWANTM Class A compatible
    • Frequency Hopping Spread Spectrum (FHSS)
    • Improved interference immunity
    • Improved power management for longer battery life
    • Encrypt-RF™ Security (Diffie-Hellman Key Exchange + AES-128 CBC for sensor data messages)
    • Battery Life* :
    5 years (Conditions: ambient temperature 25 °C, 20 triggers/day, txpower = 20dBm, LoRa spreading factor SF = 10)
    • Over-the-air updates (future)
    • Third-Party online wireless sensor monitoring and notification system to configure sensors, view data and set alerts via SMS text and email (optional)
    • Available third-party platform: Actility/ThingPark, TTN, MyDevices/Cayenne
    • R718X series carry magnets which can be attached to ferromagnetic materials and objects
    *Actual range may vary depending on environment.
    *Battery life is determined by sensor reporting frequency and other variables


    Technical Specifications


    Input Power DC 12V /1A ( supply with AU plug pack for ANZ) and UK plug pack for Asia
    Standby current 25mA
    Operation Current 40mA
    CO2 Sensor accuracy ± 100ppm+6% reading
    CO2 detecction Range 400-5000ppm
    Temperature and Humidity Sensor measure range -20°C ~ 55°C, 0%RH-100%RH
    Temperature and Humdity Accuracy

    ±0.5°C@25°C , Max ±0.8°C@-20°C~55°C, ±4%RH @25°C



    Tx Power 19dBm±1dBm
    Rx Sensitivity -136dBm (LoRa,Spreading Factor=12,Bit Rate=293bps ) -121dBm (FSK,Frequency deviation=5kHz, Bit Rate=1.2kbps)
    Antenna Type Build-in antenna
    Communication Range Build-in antenna
    Data Transfer Rate 0.3kbps~50kbps
    Spread Technique   LoRa/FSK
    Available Frequency   EU863-870,US902-928,AU915-928, KR920-923,AS923,CN470-510 Configured before shipment





    Operating Temperature

    -20℃ ~ 55℃

    Environment Humidity Range

    <90% RH (No condensation)

    Storage Temperature

    -40℃ ~ 85℃




    User manual:


    Battery Calculator:

    Netvox Battery Calculator

    Netvox LoRa Command Resolver:

    LoRa Command Resolver
