Sku: CB-MHF4-RARPSMA-081-3600
AUD$7.05
Availability:
Many In Stock
Sku: CB-MHF4-RARPSMA-081-3600
RF Cable & Antenna
Elecom Electronics Supply
| Style | Right Angle RP-SMA to MHF4 ( For M.2 / NGFF card) |
|---|---|
| 1st Connector | Right Angle RP-SMA Female Jack, Male Pin |
| 2nd Connector | MHF4 Coaxial Plug Female Socket |
| Cable Length | 360mm |
| Cable Type | 0.81mm OD Coaxial Cable |
| Impedance | 50 Ohm |
| Frequency - Max | 6GHz |
| Color | Black |
