Elsys LoRa ERS-Lite sensor - Integrated with Temperature / Humidity
ERS Eye is a LoRaWAN™ sensor that measures room occupancy. ERS Eye is designed to be mounted on a ceiling or wall. It senses the presence of body heat in the room by measuring the temperature in an 8×8 matrix with a 60×60 degree viewing angle. It can be used for dynamic workplace management, facility management and workplace statistics. The sensor also measures temperature, humidity and light.
The ERS Eye is powered by two 3,6V AA lithium battery (ER14505). The Battery life is estimated to be up to 5 years but depends on sample interval, transmit interval, data rate and environmental factors. You are welcome to use our online battery lifetime calculator. All Elsys sensors are equipped with NFC (Near Field Communication) for easy configuration with an Android phone. With our application “Sensor Settings“, you can change sample rate, data rate, encryption keys, triggers, activation and much more. All parameters can also be changed over the air from the server. All our sensors are built on the LoRaWAN™ stack from Semtech. Channel plans for US902-928, EU863-870, AS923, AU915-928, KR920-923.
When the sensor starts up it loads configuration from the internal memory and merge it with user configuration. When the configuration is done the sensor writes the new configuration to the NFC chip. The sensor always writes new configurations to the NFC chip when something changes in the sensor or if NFC data is corrupted by a NFC writer or phone. The sensor always writes new configuration to NFC chip at startup. When configuration is done the sensor tries to join the network if OTAA (Over The Air Activation) is enabled.The sensor led flashes orange when it tries to join a network. The sensor tries to join the network every 10 second and increases the join timer at every failed attempt by 10%, up to maximum 1 hour. After startup,configuration and join the sensor enters sampling mode.
When reading or writing NFC data to the sensor, it starts a timer and delays its actions for 5 seconds. This delay is for the possible bad connection inherited with NFC communication. Reasons for bad connection can be distance, location or rapid movement. After the delay, the sensor determines if the NFC data has changed or not. If the data has change the sensor reboots and starts from power up. When writing data to the sensor, try to get the best connectivity as possible. Locate the NFC antenna of the phone and sensor. Keep the 2 devices as close as possible and don’t move them while writing or reading. When you have written data to the sensor, let the sensor reboot and restart before trying to write again. You can always validate your settings by reading the NFC data after the sensor has restarted.
Datasheet: ERS Lite Datasheet.pdf
User Guide: ERS Lite User Guide.pdf
Setting Parameter: ERS Setting Parameter.pdf
PayLoad: Uplink Payload.pdf
Downlink PayLoad: Downlink Payload.pdf
Battery life calculator
